2020 Western Star 4700SF W21 Truck

(3) DTNA GENUINE, HIGH TEMP AGM STARTING AND CYCLING, MIN 2775CCA, 570RC, THREADED STUD BATTERIES
1/4 INCH (6.35MM) C-CHANNEL INNER FRAME REINFORCEMENT
11 FOOT 06 INCH (138 INCH+0/-5.9 INCH) EXHAUST SYSTEM HEIGHT
13 GALLON DIESEL EXHAUST FLUID TANK
1500 SQUARE INCH ALUMINUM RADIATOR
1650 RPM/18 MPH LIMIT FOR LOW GEARS, 1650 RPM/44 MPH LIMIT FOR MIDDLE GEARS, 1650 RPM/45 MPH LIMIT FOR HIGH GEARS
20,000# TAPERLEAF FRONT SUSPENSION
2008 CARB EMISSION CERTIFICATION - CLEAN IDLE (INCLUDES 6X4 INCH LABEL ON LOWER FORWARD CORNER OF DRIVER DOOR)
2021 MODEL YEAR SPECIFIED
21 CUBIC YARD DUMP BODY
4700SF W21
5225MM (206 INCH) WHEELBASE
75 MPH ROAD SPEED LIMIT
80 GALLON/302 LITER ALUMINUM FUEL TANK - LH
ALLISON 4500 RDS AUTO.
BABCOCK 2-PIECE CLUTCH BRAKE
Capacity: 12 CYD of Stone or 15 CYD Topsoil or 22 CYD Mulch or 16.5 Yards Gravel
CUMMINS X12
DETROIT DA-F-20.0-5 20,000# FLl 71.0 KPI/3.74 DROP SINGLB FRONT AXLE
DETROIT DD13 12.8L 470 HP @ 1625 RPM, 1900 GOV RPM, 1650 LB-FT@ 975 RPM
EATON ADVANTAGE 15-1/2 INCH SELF ADJUSTING CLUTCH
EATON FULLER RT0-16908LL TRANSMISSION
JACOBS COMPRESSION BRAKE
ll/32X3-l/2Xl0-15/16 INCH STEEL FRAME (B.73MMX277.BMM/0.344Xl0.94 INCH) 120KSI
MICHELIN X WORKS XDY 11R22.5 16 PLY RADIAL REAR TIRES
MICHELIN XZE2 11R22.5 16 PLY RADIAL PUSHER/TAG TIRES
MICHELIN XZY-3 425/65R22.5 20 PLY RADIAL FRONT TIRES
MITSUBISHI 12V MOD 3.175-DP60 STARTER WITH INTEGRATED MAGNETIC SWITCH
PTO MINIMUM RPM - 600
PTO MODE ENGINE RPM LIMIT - 1100 RPM
PTO RPM WITH CRUISE RESUME SWITCH - 800 RPM
PTO RPM WITH CRUISE SET SWITCH - 700 RPM
RPL20 MERITOR INTRRAXLE DRIVELINB
RPL25 MERITOR MAIN DRIVELINE
RT-46-160 46,000# R-SERIES TANDEM REAR AXLE
SET BACK AXLE - TRUCK
There are 10 to 16 Cubic Yard of Material in a fully Loaded Tri-Axle Dump Truck
TRAILER TOWING PROVISION AT BND OF FRAME WITH SAE J560
Truck has a 16ft Brandon Body Installed
WESTERN STAR 4700 SET-BACK FRONT AXLE CHASSIS
WESTERN STAR VOCATIONAL WARRANTY
WST 4700 PRL-20T (EFF:4/30/19)
