2025 Fruehauf HIGH BASE RAIL PLATE VAN Dry Van Trailer

Length   53'
Width   102"
Height   13'6"
Inspection   C-PA 6/26
Inside Width   101"
Inside Height   110"
Door Opening   110"
Sides   Plate -80K Galv Steel on Sides w Polyurethane Core
Color   White
Type Posts   Series "A" logistics posts
Post Spacing   48"Centers
Side Scuff   16" Integral Aluminum Scuff Liner
Side Lining   Plate
Nose Lining   Dymond Panel Full Hgt, .175" Lower 34" .056" Above
Nose Scuff   5/8 THK x 12" High HDPE Black Front Wall Scuff
Rear Doors   Swing
Hinges   4 - Aluminum
Roof    Aluminum
Roof Bows   Anti-Snag, 24" Centers
Rear Frame   Galvanized
Bumper   Bolt-on, Galvanized
Rubber Dock Bumpers   Yes
Van Floor   1 3/8" Lam. Hardwood, 3 Screws per Board
Threshold Plate   25 5/8" Diamond Plate-Full Width Galvanized
# of Axles   2
Suspension Type   Air Ride
Suspension Brand   Holland CBX40 AeroBeam with PosiLok and AiRelease
Suspension Setting   49"
Tire Size   295/75R22.5
Wheels   Steel
Tire %   1/70% 4/50% 3/40%
Brake %   30-40%
King Pin Setting   36"
5th Wheel Condition   GOOD
Cross Member Center   9" Centers Thruout w 2 Extra at Landing Gear
Landing Gear   Jost, Two-Speed
