2025 TESAB 200TCR Crushing Plant

2025 TESAB 200TCR

HEAVY DUTY MOUNTED CONE CRUSHER
- MC200 CONE
- TRACKED
- INTEGRATED HOPPER WITH FOLDING REAR DOOR
- I-BEAM PLATE FABRICATED CHASSIS CONSTRUCTION
- LARGE GAP BETWEEN CRUSHER DISCHARGE AND MAIN CONVEYOR FEEDBOOT
- OPEN CHASSIS DESIGN FOR EASE OF MAINTENANCE
- FAST SETUP TIME

LENGTH: 60' - 9"
WIDTH: 11' - 5"
HEIGHT: 11' - 2"
WEIGHT - TRACK: 106,770 LBS

DIESEL TANK CAPACITY: 157 GAL
HYDRAULIC TANK CAPACITY: 172 GAL

FEED OPENING: 38"
CRUSHER INPUT SPEED: 750 - 950 RPM
CRUSHER DRIVE: DIRECT DRIVE
MIN. OPENING: 3.74"
MAX OPENING: 7.28"
CONE WEIGHT: 22,928 LBS
CLOSED SIDE SETTING ADJUSTMENT: HYDRAULIC
LEVEL SENSOR: ULTRASONIC
POWER REQUIRED: 200 HP
