2026 Palfinger | Crane | PSC8029 Truck-Mounted Boom / Crane

2026 Palfinger | Crane | PSC8029

Take on the toughest jobs with PALFINGER hydraulic service cranes - 8,000-14,000 lb capacity, 29' reach, and excellent weight-to-lift ratio. The standard multi-function remote and high-speed winch keep you efficient, while options like boom tip hooks and personnel baskets allow you to customize your crane.

Standard Features:

• 8,000lbs Lifting Capacity
• 43,000 ft.-lbs Rated Lifting Capacity With 49,180 ft.-lbs Maximum Lifting Capacity
• (2) Hydraulic Boom Extension
• Planetary Winch Provides Speed And Durability
• Horse Head Low Profile Design With Optional Boom Tip Hook(s) And Lights
• Bracket And Pads Designed To Keep Load Block From Contacting The Boom When Stowed
• Ultra-Low Maintenance High Tensile Strength Self-Centering Single Weld Hexagonal Boom Sections Powered By Internal Extension Cylinders
• Internal Extension Cylinders For 25’ Of Hydraulically Powered Outreach
• All Cylinders Are E-coated And Use A 5 Stage Marine Grade Seal System
• Features A Standard Proportional Wireless Remote Control Unit, Integrated E-Stop Button, Warning Horn, And Manual Valve Activation Capability
• Through The Control Valve, Single Function Proportional Control Of All Hydraulic Functions Is Standard
• Integrated System Prevents Wire Rope Spool Off, Ensuring Three Wraps Remain On Drum
• Intelligent Winch Console With Two-Block Damage Prevention System Is Integrated Into Winch Mounting Platform Eliminating The Need For Boom Tip Apparatus And Cord Reel

Available Options:

• PALFINGER Exclusive 2.5 Ton Capacity Boom Tip Hook
• ELS System Provides Unique Solution To Lower The Hooking Point For The Load Block in Which The Winch Is Used To Lift Load Block In Its Stowed Position
• With The Addition Of A Retractable Cord Reel Bring Power To The Boom Tip To Light Dual Work Lights That Swing Freely While Raising And Lowering The Boom To Illuminate Working Area
• Non-Marring Boom Rest That Supports The Crane While Protecting The Paint Finish
• Support Your Lifting Application Needs With Manual And Hydraulic Outrigger Options
• Paddle-Style Controller Offers The Possibility To Completely Eliminate The Radio Signal When The Cord Is Plugged Into The Receiver
• Remote Options Include Protective Case With Belt Loop, Silicone Cover, And Remote Storage Bracket Mounted In-Cab Or In Crane Compartment
• Pistol-Grip And Push-Button Remote Controls Available
• Personnel Basket With Quick-Connect Setup, 37' Reach, Collapsible Storage Box, And Lightweight Design Available

Call for more information and pricing!
