2027 Dorsey LB35-33CS W/SPRING RAMPS Drop Deck Trailer

FET Included in the price.

Length 45' 4"
Width 102"
Top Deck Length 13' 10" - Front to Main Deck (Thru Transition)
Main Deck Length 27'
Main Deck Height 33" Loaded
Flat Body
Beavertail 4' Steel with Traction Bars
Ramps 72"x24" - Spring Assisted - Angle Iron Ramps
D-Rings 8 Pair
Floor 1 1/2" Apitong
Side Rail 12" Fabricated I-Beam
Winch Track None
Toolbox Tool Box in Gooseneck
Suspension
# of Axles 2
Suspension Type Spring Ride
Suspension Brand Hutchens
Suspension Setting 49" Closed Tandem
Tire Size 235/75R17.5
Wheels Steel 17.5, Hub-Pilot
UnderFrame
King Pin Setting 18"
Cross Member Center 8" I-Beams
Paint Black
Comments
35-Ton Capacity
Main Beams - 16" Fabricated Main I-Beams
Gooseneck - Flat Deck Wood Filled Top Deck w 21 Degree Slope - Steel w Traction Bars
8' 4" Top Deck Length - Flat
5' 6" Transition Length
84" Swing Clearance
5/16" Thick King Pin Plate
48" 5th Wheel Height
Wheel Wells Covered with Steel Plate & Transction Bars
Two-Speed Landing Gear
4-Leaf Spring Suspension
