Product Description
SKU: EH6845
It comes with auto grease, Chisels, Seal kits, Toolbox, include hoses & couplings
Operating pressure: 110-140kg/cm² (1562-1988 psi / 108-137 bar)
Hydraulic flow range: 40-70l/min (10.5-18.5gal/min)
Impact frequency: 500-900bpm
Impact Energy: 590-630J
Diameter of hose: 12.7mm/1/2inch
Diameter of Tool: 68mm/2.68inch
Weight of Tool: 18kg
Suitable Carrier: 0.15-0.3m³
Suitable Carrier: 4-7ton
Valve Type: Inward
Accumulator exists: No
Body Weight: 156kg
Total weight: 350 kg
Length: 53.9 in
Width: 17.7 in
Height: 25.6 in
Compatible Models
• CAT: 45mm Pin Excavators 304CCR, 305CCR, 305DCR, 305ECR, 305.5DCR, 305.5ECR, 306
• Case: CX47, CX50B Excavators
• Daewoo: Solar 055, Solar 055V, Solar 055V PLUS Excavators
• Doosan: S55-V Excavator
• IHI (Chieftain): 40G, 40H, 45J, 45NX Excavators
• Kobelco: SK45, SK45SR, SK40SR-2, SK40SR-3, SK45SR-2, SK45SR-3, SK50UR-2, SK50SR-3, 45SR-2, 50SR-3 Excavators
• Kubota: KH151, KH161-3, KH191, KX151, KX161-2, KX161-3, KX191, RX501, U45 Excavators
• New Holland: EH50.B Excavator
• Takeuchi: TB45, TB145, TB53FR, TB53R Excavators
• Yanmar: B50-2B Excavator
