Product Description
Quality used alternator for a Cummins 8.3L engine and various others, backed by our standard warranty.
Brand Name PRESTOLITE
Voltage 12 Product Family 4000 Series
Neg Stud Size 5/16-18 Positive Stud Size 5/16-18
Rectifier Location Internal Shaft Diameter .8736-.8741
Brush/Brushless Brush Amperage Rating 270
Fan Type External Rotation Direction Clockwise
Regulator Type External Mounting Type PAD
Item number:A0014975PAA
Sales number:4975PAA
Series number:4800-4900
Notes:-40F TO +230F, USE WITH REMOTE MOUNT REG.
System voltage:12
Output:270
Mounting style:PAD
Dimensions in:INCHES
Rotation:CLOCKWISE
Housing coating:RAW
UL Approved:No
Positive stud:5/16-18
Negative stud:5/16-18
Rectifier location:INTERNAL
Shaft diameter:.8736-.8741
OEM # 04201300A, 00103211, 4975Paa, 710035057, Zln4975paa, 4975Paa 4975Paa, A1004975paa, ZLN4975PAA, L-N4975PAA, 4939AAH, A0014975PAA, 4975PAA, 8600094, MA4975PAA, A0014939AAH, 00103211, 103211, LN4975PAA, A0014939AAH-B, A0014975PAA-B, LN 4975PAA, 710035057, 04201300A, 8600094, UM00007130, A0014975PAA, 3507-2012, 180614, A-7001
Please Note: The part sent may not exactly match the one pictured. Appearance may vary. For specific part requests, please call 888-315-2575. Additional core charge may apply.
