2024 XL Specialized XL110HDGS15 - GALV W/ HYDR FLIP Lowboy Trailer

Length 53'
Width 102"
Top Deck Length 13'
Main Deck Length 26'
Main Deck Height 15" Loaded with 4.5" Ground Clearance
Rear Deck Length 14'
Weight 25,920 Lbs +/- 3% - GVWR 135,920 Lbs
Flat Body
Compatibility Hydraulic Flip Axle Connections at Rear
Floor Apitong
Ramps 31" Ramps
Side Rail Perimiter Beam - Steel
Outriggers Swing Out Outriggers on 24" Centers
D-Rings 8 Pair
Toolbox Main deck behind gooseneck
Strobe Lights Yes with battery back up
Flag Holders 2 Pair
Rear Bogie 14' with open wheel wells
Gooseneck
Gooseneck Hydraulic Detachable, Non-Ground Bearing
Loaded 5th Wheel 51" with Five Ride Height Positions
Suspension
# of Axles 3
Suspension Type Air Ride
Suspension Brand Hendrickson
Suspension Setting 54.5" axle spacing
Lift Axle Air Lift Rear
Manual Dumpvalve Yes
Raise & Lower Valve Mechanical Ride Height Control Valve
Tire Size 275/70R22.5
Tire % 85% Original
Wheels Aluminum/Steel
Brake % 85% Original
Liquid Filled Gauge Yes
UnderFrame
King Pin Setting 16"/42"
Cross Member Center 6" & 4" I-Beams on 12" alternating centers
Paint Entire Trailer Galvanized, Sides Painted Black
Weight Ratings 55 Ton in 12' Length
Comments
Sale Price includes 2024 Galvanized Hydraulic Flip Axle
