2026 IRON LITE Vacuum Tank Trailer

2026 IRON LITE Steel Vacuum Trailer

• Capacity: 130 Barrel, 5460 Gallon
• Weight: 16,980 LBS Empty weight
• Shell: 1/4" Thick 60" Diameter, Straight Cylinder, SA-36 Mild Steel
• Heads:1/4" Thick 60" Diameter, Dished
• Stiffening Rings: (8) 3"Cold Rolled Rings, External Structural Steel
• Baffels: (2) 1/4" Flared and Dished Surge Style
• Chassis: 1/4" Formed Full Length
• 4 Spring Standard, Air Ride Optional
• Tandem Axles (2) 30,000 lbs Axles with 77 1/2 track
• 2S/1M ABS Brake System
• 11R24.5 Tires Cut and Chip Resistant
• Hub Piloted Steel Wheels Standard, Aluminum Optional
• Brakes: 16.5" X 7 Maxi chambers both axles, Auto adjusting Slack Adjusters
• Upper Coupling: Bolt on. 3/8" King Plate Plank
• Landing Gear: 2 Speed Heavy Duty
• Bumper: 4" square 1/4" Thick ICC Style
• Fenders: Full Length Formed Trays
• Outlets: (2) 4" with Butterfly valve at Rear Sump of Trailer
• Manways: (4) 3 Located on top of vessel, one in rear head. 21' Domed Style with Plated swing bolts with wing nuts
• Scrubbers: primary nd secondary plumbed 4"
• Lighting: Full LED DOT certified sealed and one piece harness. (2) Work lights mounted AFT. 1 Strobe
• Level Gauge: Plumbed for Sight Glass
• Coatings: All Surfaces White Metal Sandblasted, Interior lined with Chemical Resistant 85% Solids Epoxy Liner 10ml dry film thickness, Exterior coated with high Build Epoxy Primer and Color Coated with high solids polyurethane, 4ml dry film thickness. Available in a wide range of Colors, as well as color Match
