2026 Fontaine MAGNITUDE 60DSR DROP SIDE Lowboy Trailer

Length 52' 3"
Width 102"
Top Deck Length 11' 11" Gooseneck
Main Deck Length 26'
Main Deck Height 14.5" at Side Rails; 23" at Main Beams
Weight 24,784 Lbs. +/-3%
Unit Description Magnitude 60DSR
Flat Body
Compatibility Designed to Accept Flip Neck Extension & Flip Axle
Floor 1.5" Nominal Wood - Side Rails Only
Side Rail Drop Side Rail - Steel
Outriggers 13 Pair, Removable Swing Type
D-Rings 19 Pair
Toolbox Two Covered Trays Between Mainbeams
Rear Lights (3) Stop/Tail, (3) Clearance
Strobe Lights Amber Strobes with Battary Power
Flag Holders One Pair at Front of Deck, One Pair on Bumper
Modular Connection Fixed
Gooseneck
Gooseneck Hydraulic Detachable, Non-Ground Bearing
Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50"
Suspension
# of Axles 3
Suspension Type Air Ride
Suspension Setting 54.5" Axle Spacing
Lift Axle Air Lift Rear
Manual Dumpvalve Yes
Raise & Lower Valve Mechanical Ride Height Control Valve
Tire Size 275/70R22.5
Wheels Aluminum/Steel
Liquid Filled Gauge Yes
UnderFrame
Paint Black
Weight Ratings 60 Ton in 13' Length w/ Closed 4-Axle
Comments
102" Swing Clearance
Low Boom Well
Chain Lift Axle on Front Axle
Hammer Plate (16"x60"x1/2") installed over recessed crossmembers. Perforated plate under hammer plate forming two storage
areas. 2 lashing rings located in last two deck sections.
SALE PRICE INCLUDES FET
