2027 Fontaine MAGNITUDE 60LCC Lowboy Trailer

Price includes FET
Must be purchased with Unit V35A7493 - Hydraualic Flip $29,950
Length 52'3"
Width 102"
Main Deck Length 26'
Main Deck Height 18"
Weight 24,051 lbs.
Unit Description Magnitude 60LCC
Flat Body
Compatibility Designed to Accept 35" Neck Extention & Flip Axle
Floor 2" Nominal Wood - Side Rails Only
Ramps Manual Front approach ramps
Outriggers 13 pair - Removable Swing Type / 2 pair removable
D-Rings 19 pair
Toolbox 2 Trays - fully Covered between main beams
Side Rail Lights (3) Marker LIghts per Side incl. Mid-Turn
Rear Lights (3) Stop/Tail, (3) Clearance
Strobe Lights Battery Powered Rear Amber Strobes
Flag Holders 1 Pair
Modular Connection Fixed
Gooseneck
Gooseneck Hydraulic Detachable, Non-Ground Bearing
Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50"
Pony Motors None
Suspension
# of Axles 3
Suspension Type Air Ride
Suspension Setting 54.5"
Lift Axle Rear Axle Air Lift
Flip Axle Not Included
Manual Dumpvalve Yes
Raise & Lower Valve Mechanical Ride Height Control Valve
Tire Size 275/70R22.5
Wheels (6) Polished Alum (6) Steel Disc
Liquid Filled Gauge Yes
UnderFrame
King Pin Setting 16"
Cross Member Center 24" Centers
Paint Black
Weight Ratings 60 Ton in 13' Length w/ Closed 4-Axle
Hydraulic Flip Axle Option Included
Compatibility with Spreader Bar and/or 35" Flip Box
7 Variable ride Height Positions
102" Swing Radius
Removable Kingpin at 102" Radius
Low Boom Well
Chain Lift Axle on Front Axle
