2023 KLEEMANN MSS 802I EVO Screening Plant

MOBILE SCREENING PLANT -
APRON FEEDER -
WITHOUT MAGNETIC SEPARATER -
POWER SUPPLY UNIT JOHN DEERE STAGE V -
PUNCHED PLATE HOLE DIA 100MM PACKAGE SEGMENT 1-4 2 -
WITHOUT SCREEN MESHES , WITHOUT DISTANCE FRAME AND -
SIDE DISCHARGE CONVEYOR LOWER DECK OVERFLOW, LEFT -
CRUSHER DISCHARGE CONVEYOR STUD BELT -
SIDE DISCHARGE CONVEYOR, LOWER DECK UNDERFLOW RIGHT -
WITHOUT EXTERNAL POWER SUPPLY -
WITOS FLEETVIEW -
HOPPER UNIT 9,1 M3 -
MAY BE SUBJECT TO NEW EQUIPMENT SALES TAX -

Factory Features -
TYPE: Mobile Coarse Material Screening Plant -
SCREEN TYPE: Double-Deck Scalping Screen -
DRIVE SYSTEM: H-DRIVE Diesel-Hydraulic -
ENGINE: John Deere Tier 4 Final -
ENGINE POWER: 133 HP -
MAX PRODUCTION: 551 TPH -
MAX FEED SIZE: 32 in x 20 in x 12 in -
HOPPER CAPACITY: 11.9 yd³ -
FEED HEIGHT: 11 ft 9 in -
HOPPER DISCHARGE CONVEYOR: 56 in x 14 ft 9 in -
SCREEN TOP DECK: 5 ft 1 in x 16 ft -
SCREEN BOTTOM DECK: 5 ft 1 in x 14 ft 9 in -
FINE GRAIN CONVEYOR: 48 in x 14 ft 4 in -
FINE MATERIAL CONVEYOR: 36 in x 25 ft 6 in -
FINE MATERIAL DISCHARGE HEIGHT: 9 ft 9 in to 13 ft 1 in -
MEDIUM MATERIAL CONVEYOR: 36 in x 25 ft 6 in -
MEDIUM MATERIAL DISCHARGE HEIGHT: 7 ft 7 in to 11 ft 11 in -
OVERSIZE CONVEYOR: 56 in x 19 ft 11 in -
OVERSIZE DISCHARGE HEIGHT: 8 ft 8 in to 13 ft 3 in -
TRANSPORT LENGTH: 52 ft -
TRANSPORT LENGTH EXTENDED: 55 ft 1 in -
TRANSPORT WIDTH: 9 ft 10 in -
TRANSPORT HEIGHT: 11 ft 2 in -
OPERATING WEIGHT: 70,350 lb -
MAX CONFIGURATION WEIGHT: 84,900 lb -
TRACK UNDERCARRIAGE -
VARIABLE SPEED HOPPER FEEDER: Optional -
APPLICATIONS: Quarry, Aggregate, Topsoil, Recycling, Demolition Material, Heavy Scalping Applications -

Specifications and features are based on general factory information and may not reflect the exact machine being offered. Please contact RDO Equipment Company to verify machine specifications, options, attachments, and condition.
