2026 XL Specialized XL80HDEM Lowboy Trailer

New 2026 XL80 HDE hydraulic detach extendable mini deck:

48'x102"
80,000 LB DISTRIBUTED CLOSED, 80,000 IN 16' CLOSED CENTERED ON THE DECK
30,000 LB IN 5' FRONT AND REAR OF DECK FULLY EXTENDED - 00,000 LB TO TAL
CLASSIC NECK, 10'5" length
16" KINGPIN SETTING
84" SWING CLEARANCE
49" 5th WHEEL HEIGHT W/ 7 VARIABLE RIDE HEIGHT POSITIONS
13 HP HONDA SCA, DUAL HYDRAULICS, STEEL COVER
PREP FOR 36" FLIP NECK EXTENSION
EXTENDS FROM THE FRONT
28' 3" / OPENING TO 49' 8"
14° W/ 4* GROUND CLEARANCE
1 1/8* APITONG DECKING, FLUSH
FORMED CROSSMEMBERS ON 24* CENTERS
10* FABRICATED
(11) BENT D-RINGS PER SIDE
SWINGOUT OUTRIGGERS BRACKETS ONLY- 24* CENTERS
9' 4" REAR DECK, 55° SLOPE
40" LOADED DECK HEIGHT
(2) 25,000 LBS AXLES
HENDRICKSON / 25,000 CAPACITY/ AIR RIDE
54" AXLE SPACING
4S2M WITH SPRING BRAKES ON ( 2) AXLES
255 / 70R / 22.5 (H) TIRES
8.25 X 22.5 10-HOLE PILOT MOUNT POLISHED ALUMINUM OUTSIDE, STEEL INSIDE DISC
OUTBOARD DRUM BRAKES
12V SEALED GROTE SYSTEM WITH ( 3) TAIL UGHT ALUMINUM PACKAGE
4* AMBER STROBE TO BE USED AS 3RD TAIL UGHT
BATTERY BACKUP
1 1/8* APITONG DECKING FLUSH, COVERED WHEELS
(1) PAN STYLE D-RING IN EACH CORNER
(2) BENT D-RINGS IN TAIL CHANNEL
BLACK
(2) PAIR EZ MOUNT FLAG HOLDERS
MANUAL RIDE HEIGHT CONTROL
PREP FOR FLIP AXLE
COLAS+ RAISE AND LOWER VALVE
EXTENSION STOPS ON 24* CENTERS
STORAGE AREA AT REAR OF FEMALE DECK
31* FRONT FLIP RAMPS
BLACK DURABAK ANTI-SKID COATING ON MALE AND FEMALE TOP FLANGES
2 X 2 CUT OUT IN REAR TRANSITION
(2) ADDITIONAL CLEARANCE LIGHTS PER SIDE ON MAIN DECK
(1) PAIR OF BENT D-RINGS ON MALE DECK BELOW THE BACKSIDE OF THE GOOSENECK BASE
LIQUID FILLED AIR GAUGE
(3) PAIR OF KEYSLOT CHAIN DROPS IN THE FRONT OUTSIDE EDGES OF THE MALE DECK

FOB Manchester, IA
***These trailers can be shipped nationwide***
